2 Sets 0.5T Suspension Single Girder Bridge Crane with Electric Chain Hoist to America
2017-05-22
Key Facts
2sets
Technical Parameter
- Capacity: 0.5t
- Span:5.486m
- Lifting height:3m
- Cantilever(Both side): 0.305m
- Lifting Speed: 6.9/2.3m/min
- Power supply: 208/60hz/3ph
- Hanging Distance: 1.2m
- Lifting mechanism is electric, traveling mechanism is manual.
Detailed Informaiton
Today we finished 2sets 0.5T Suspension Single Girder Bridge Crane to America. It will be used on to lift glass.
According to customer requirements, we design the lifting mechanism is electric, traveling mechanism is manual. Customer plant situation is more complex, we provide customers with the runway beam, rail to facilitate customer installation. In addition, the customer has added 16 sets of hanging devices for the roof.
Suspenstion crane is actually a series of belonging to a single beam suspension, but do not use I-beam, multi-purpose C steel and hanging pieces combinations. Structure is relatively simple. But the load-bearing capacity is limited, lifting generally use the chain hoist.
Main Beam
Rails
Suspend device
